Directional pattern: Supercardioid
Principle of operation: Pressure gradient
Cartridge type: Pre-polarized condenser
Effective frequency response: 20 Hz - 20 kHz
Frequency range, ±2 dB, at 12 cm (4.7 in): 100 Hz - 16 kHz. Permanent 3rd order low-cut filter at 80 Hz
Sensitivity, nominal, ±3 dB at 1 kHz: 5 mV/Pa; -46 dB re. 1 V/Pa
Equivalent noise level, A-weighted: Typ. 22 dB(A) re. 20 µPa (max. 23 dB(A))
Total harmonic distortion (THD): < 1% up to 139 dB SPL peak
Dynamic range: Typ. 117 dB
Max. SPL, peak before clipping: 160 dB
Output impedance: 150 Ω
Minimum load impedance: 1 kΩ
Cable drive capability: 100 m (328 ft)
Output balance principle: Impedance balancing with Active Drive
Common mode rejection ratio (CMRR): > 50 dB at 1 kHz
Power supply (for full performance): 48 V Phantom power (±4 V)
Current consumption: Max 2.5 mA
Connector: XLR-3M. Pin 1: shield, Pin 2: signal + phase, Pin 3: - phase
Weight: 286 g (10.1 oz)
Diameter: 48 mm (1.9 in)
Capsule diameter: 19 mm (0.75 in)
Microphone length: 188 mm (7.4 in)
Maximum output voltage, RMS: 9 Vrms; 19 dBV; 28 dBu
Polarity: +V at pin 2 for positive sound pressure
