Sub12 is a highly articulate subwoofer offering a level of definition, dynamics and sub-bass that is unrivalled in its price bracket. Thanks to its high excursion woofer and 1000W peak amplification, the Sub12's transcription is more powerful and truer than ever.

Key points

• Composite sandwich ‘W’-cone: sound neutrality, no distortion
• Large laminar port: no port noises or distortion
• Automatic disengageable stand-by mode
• Amplification: 600W RMS, 1000W peak
• Carry handle

Monitor Type Active 2-Way

Enclosure Bass-Reflex, Shielded

Power Rating

• 600 W RMS
• 1000 W Peak

Drivers LF Driver: 1 x 13" / 33 cm Composite Cone

Amplification 1 x LF Amplifier: Rated at 600 W RMS / 1000 W Peak Performance

Frequency Response 30 Hz to 400 Hz ± 3 dB

Maximum Sound Pressure Level (SPL) 124.5 dB

Analog Input Sensitivity/Gain +4 dBu / -10 dBV (Fixed)

Phase Adjustment 0 to 180° Continuous Phase Control

Protections and Limiting Fuse

Filters

• 1 x High-Pass at 45 to 90 Hz
• 1 x Low-Pass at 50 to 150 Hz

Audio I/O

• 2 x XLR Balanced Female Analog Input (10 Kilohms)
• 4 x XLR Balanced Male Analog Output/Thru (50 Kilohms)

AC Input Power 100 to 240 VAC, 50/60 Hz

Enclosure Material MDF

Dimensions (W x H x D) 19.2 x 23.6 x 22.4" / 48.7 x 60 x 56.8 cm

Weight 127.8 lb / 58.0 kg
