- Amp Type
-
Tube
- Chassis Material
-
Aluminum
- Rectifier Type
-
Silicon Diodes
- Rectifier Tubes
-
n/a
- Variac Power Switch
-
n/a
- Preamp Tubes
-
5x Mesa 12AX7
- Power Amp Tubes
-
2x Mesa 6L6
- Bias Switch for Alternate Power Tubes Types
-
n/a
- Maintenance Free Fixed Bias
-
Yes
- Wattage(s) Quick Reference
-
50 or 25 Watts via single, global 50/25 Watt Power Switch - See Power Amp Details for more information
- Built-In Power Amp Attenuation
-
n/a
Power Amp Details (Class & Wattage)
Class A/B Power with a single, global 50/25 Power Switch, each setting featuring a different wiring configurations (Pentode or Triode respectively). Choose from 2 power tubes operating in Class A/B Triode for lush harmonics and a sweet, liquid feel at lower volumes, producing 25 Watts or; 2 tubes operating in Class A/B Pentode for maximum power, punch and clarity, producing 50 Watts
- Convection or Fan Cooling
-
Convection
- Number of Footswitchable Channels (or Modes)
-
Two Channels
- Number of Style Modes
-
Three
- Number of Style Modes Per Channel
-
Three (Channel Cloning™)
- Types of Style Modes Per Channel
-
Ch. 1 = Clean, Drive or HI (Channel Cloning™)
Ch. 2 = Clean, Drive or HI (Channel Cloning™)
- Channel Controls
-
Each Channel features Independent 3-Position Channel Cloning™ Mode Switch, Gain, Treble, Mid, Bass, Presence, Reverb and Master
- Graphic EQ and/or Contour
-
n/a
- Reverb / Effects & Bypass Options
-
All-Tube, Spring Reverb with Independent Channel Controls
- Effects Loop & Bypass Options
-
Fully Buffered Series FX Loop
- Global Output Level Control
-
n/a
- Global Solo Level Control & Bypassable Options
-
n/a
- True-Bypass Options
-
n/a
- Tuner Output
-
n/a
External Switching Jack Options and/or MidiExternal Switching Jack for Reverb On/Off (Reverb Footswitch and Cable sold seperately)
- Speaker Outputs
-
One 8 Ohm and Two 4 Ohm
- Cabinet Simulation - Direct Live/Recording Output
-
n/a
- Headphone Output
-
n/a
- Slave Output
-
n/a
- Weight
-
26 Lbs.
- Dimensions
-
9 3/4" H x 22 3/4" W x 9 1/2" D
