From Rupert Neve Designs
The 5045 Primary Source Enhancer is exceptionally useful at reducing feedback without negatively impacting the sonic integrity of the source signal, effectively increasing the level a microphone can be raised before feedback occurs in a live sound environment by up to 20dB. With controls that are very simply laid out and generally require minimal adjustment, the 5045 is an invaluable tool for churches, stadiums, performance halls, or any venue where feedback is problematic.
100% Analog Design
The 5045 shares some traits with conventional “noise gates”, but operates on a different principle. One common aspect is that both reduce the gain during the absence of signal – or more specifically, both begin to attenuate when the level of a signal falls below a certain user-defined threshold. The 5045 senses when someone is speaking or singing into the mic and allows the signal to pass through, and senses when the person has stopped talking or singing and reduces the gain appropriately, thus reducing the system’s tendency to feed back.
Importantly, the 5045 does not utilize filtering or digital processing to achieve its significant benefits. Built around Rupert Neve Designs’ custom input and output transformers, its all-analog circuitry provides superb control and sonic performance without compromising the integrity of the source material. This makes the 5045 the most intuitive, natural-sounding and effective method of feedback reduction available on the market.
Simple, Intuitive Controls
With a minimal control set, the 5045’s ease of use makes it ideal even for circumstances where a full-time or experienced engineer is not readily available, and allows for rapid adjustments on-the-fly even during performances.
The 5045 is an absolutely indispensable addition to any setup where feedback or reverberation are problematic, and is used every night on the biggest stages all across the world.
- Maximum Input and Output Level
- +25 dBu
- Total Harmonic Distortion and Noise
- Better than 0.002%
1 kHz, +20 dBu Output Level, no load
Noise (Measured at Main Output, un-weighted, 22 Hz - 22 kHz, 50 ohm balanced source)
- Primary Source Enhancer Bypassed
- Better than -100 dBu
Primary Source Enhancer Engaged Better than -95 dBu
Frequency Response
- 150 kHz
- -3 dB
- 20 Hz
- -3 dB
- Threshold
- Continuously variable from -20 dBu to +10 dBu
- Depth
- Continuously variable from 0 dB to -20 dB
Time Constants
RMS Mode
Attack AND Release
Mode A 50 mS
Mode B 100 mS
Mode C 200 mS
Mode D 750 mS
Mode E 1.5 S
Mode F 3 S
Peak Mode
Attack (fixed) 20 mS
Release
Mode A 20 mS
Mode B 200 mS
Mode C 1 S
Mode D 2 S
Mode E 5 S
Mode F 30 S
- Power Requirements (12V DC)
- 1 Amp
- Shipping Dimensions
- 26“ (66.04 cm) x 15” (38.1 cm) x 5” (12.7 cm)
- Shipping Weight
- 11 lbs, 5
