Studio Projects C1 Large Diaphragm Condenser Microphone Quick n' Dirty
In this video, Sound Pure pro audio expert Nick Prather describes the many benefits of the Studio Projects C1 Large Diaphragm Condenser Microphone.
Free 3-Year Warranty
Sound Pure's Take
Like the rest of the line, the C1 rivals microphones costing as much as five to ten times its price. Awesome for low-budget studios that demand high quality vocal recordings. It also doubles well on instruments and anywhere else you'd need a high-quality condenser. If you want to step up a bit, try checking out their C3, or possibly even their extremely fine T3!
From Studio Projects
The Studio Projects C1 is a large diaphragm, fixed-cardioid condenser microphone employing a 1.06' (27mm) capsule, high quality, low noise amplifier and balanced, transformerless output circuitry. It features switchable -10dB pad and 6dB@150Hz high pass filter for added control in various recording applications and a clear, full response expected from a large capsule microphone design.
Versatility is key in the recording arena, and the Studio Projects C1 is a well-proven and award winning tool. It is designed to deliver the finest quality vocal and instrumental recordings and will serve to enhance any professional or project studio at an unbelievably low price.
As a result of uncompromising dedication and advanced production capabilities, Studio Projects will continue to broaden the range of quality pro audio microphones & electronics for today's recording environment.
Features:
- Pressure-Gradient Transducer: 1.06" (27mm) 6um mylar diaphragm
- High Pass Filter
- -10db Pad
Applications
- Close miking of instruments with high sound pressure levels
- Announcer’s mic for broadcasting/dubbing
- Home recording and project studios
- Vocalist recording
- Spot mic for: wind instruments, strings, percussion and guitar
Included Accessories
- Shock mounted elastic suspension
- Foam wind screen
- Case
- Type
- Pressure gradient solid state condenser microphone
- Polar pattern
- Cardioid.
- Frequency response
- 30~20000Hz.
- Sensitivity
- 14mV/Pa=-37dB(0dB=1V/Pa).
- Output impedance
- <200 Ohm.
- Load impedance
- >1000 Ohm.
- Maximum SPL
- 131 dB SPL for 1% THD @1000Hz (0dB SPL=0.00002Pa).
- Noise
- (Line): 27dB (A weighted)---17dB.
- S/N
- 77dB.
- Power requirement
- 48 +/- 4V.
- Current consumption
- <2.5mA.
- Circuit
- JFET impedance converter, discrete balanced output.
- Connector
- Gold-plated 3-pin XLR
- Size
- dia: 2.1" length: 8.9"
- Weight
- 26.9oz
- Pad
- -10dB, -20dB
- Low cut
- 6dB/Octave at 75Hz or 150 Hz.
Watch & listen
Budget FET Vocal Mic Shootout: Lauten LA-220 v. Studio Projects C1 v. Miktek C1 v. Avantone CK-7
Also in this recording Lauten Audio LA-220 FET LDC Microphone V1 Miktek C1 Cardioid Large Diaphragm FET Condenser Microphone Avantone CK-7 Large Diaphragm FET Multi-Pattern Condenser Warm Audio WA76 Discrete Compressor Bricasti Design M7 Reverb Processor SoundToys EchoBoy - Delay Plug-in
In this video we present a budget friendly FET vocal microphone shootout using the Lauten LA-220, the Studio Projects C1, the Miktek C1, and the Avantone CK-7. Can you tell which one's which? If you are interested in hea... Read more
In this video we present a budget friendly FET vocal microphone shootout using the Lauten LA-220, the Studio Projects C1, the Miktek C1, and the Avantone CK-7. Can you tell which one's which? If you are interested in hearing the results and/or getting ahold of the audio files from this shootout, give us a shout, we'd love to hear from you!
